1200 Air-Cooled Worktop Freezer(-22~-18°C)
Highlights
- Single-temperature commercial freezer
- Temperature range: -22~-18°C
- High-efficiency forced-air cooling system
- Smart airflow circulation for even temperature distribution
- Environmentally friendly R290 refrigerant (GWP=3)
- Stable freezing performance with minimal temperature fluctuation
- SUS201 stainless steel interior and exterior construction
- Electric auto defrost with condensate self-evaporation
- Front-access removable filter for easy maintenance
The YTA-120F FZ Air-Cooled Worktop Freezer is a compact and reliable commercial freezing solution designed for restaurants, bakeries, cafés, hotel kitchens, catering operations, and professional food preparation environments. Combining frozen storage with a durable stainless steel worktop, it maximizes kitchen efficiency while ensuring stable low-temperature performance.
Equipped with an advanced forced-air refrigeration system and intelligent airflow circulation technology, the unit maintains a consistent temperature range of -22~-18°C, helping preserve frozen food quality and reduce temperature fluctuation during intensive commercial use.
Built with high-quality SUS201 stainless steel inside and out, the freezer offers excellent durability, corrosion resistance, and hygienic performance. Powered by environmentally friendly R290 refrigerant, the YTA-120F FZ delivers energy-efficient refrigeration with low environmental impact.
Its space-saving undercounter design and integrated stainless steel work surface make it an ideal solution for modern commercial kitchens with limited workspace.
Highlights
- Single-temperature commercial freezer
- Temperature range: -22~-18°C
- High-efficiency forced-air cooling system
- Smart airflow circulation for even temperature distribution
- Environmentally friendly R290 refrigerant (GWP=3)
- Stable freezing performance with minimal temperature fluctuation
- SUS201 stainless steel interior and exterior construction
- Electric auto defrost with condensate self-evaporation
- Front-access removable filter for easy maintenance
- Rounded interior corners for hygienic cleaning
- Heavy-duty foamed-in-place structure for durability
- Electrophoresis-coated anti-corrosion evaporator
- Optional LED lighting and door lock
- Optional adjustable casters or feet
- Optional SUS304 stainless steel upgrade
- Optional RS485 ModBus communication interface
- Suitable for commercial kitchens up to 43°C ambient temperature
Technical Specifications
| Item | Specification |
|---|---|
| Model | YTA-120F FZ |
| Product Type | Air-Cooled Worktop Freezer |
| Temperature Range | -22~-18°C |
| Cooling Unit | Self-contained |
| Refrigeration Capacity | 350W |
| Refrigerant | R290 (GWP=3) |
| Refrigerant Charge | 60g |
| Refrigeration System | Forced Air Circulation |
| Defrost System | Electric Defrost, Microprocessor-Controlled |
| Insulation Material | Cyclopentane |
| Insulation Thickness | 60 mm |
| Exterior Material | SUS201 Stainless Steel + Galvanized Back/Bottom |
| Interior Material | SUS201 Stainless Steel |
| Shelves | 2 pcs Plastic-Coated Food-Grade Shelves |
| Feet Height | H100~120 mm |
| Optional Casters | H128 mm Adjustable Casters |
| Voltage | 220-240V AC / 50-60Hz |
| Rated Power | 190W |
| Rated Current | 1.88A |
| Climate Class | 4 |
| Operating Ambient Temperature | 5~43°C |
| Test Standard | ISO 22041 |
Dimensions & Capacity
| Configuration | 600D | 700D | 800D |
|---|---|---|---|
| Net Capacity | 198L | 242L | 285L |
| Gross Capacity | 203L | 247L | 290L |
| External Dimensions (W×D×H) | 1200×600×800 mm | 1200×700×800 mm | 1200×800×800 mm |
| Internal Dimensions (W×D×H) | 880×412×570 mm | 880×512×570 mm | 880×612×570 mm |
| Door Swing Space | 1200×968×800 mm | 1200×1068×800 mm | 1200×1168×800 mm |
| Package Dimensions | 1230×630×860 mm | 1230×730×860 mm | 1230×830×860 mm |
| Net Weight | 55 kg | 57 kg | 59 kg |
| Gross Weight | 65 kg | 67 kg | 69 kg |
Applications
The YTA-120F FZ commercial worktop freezer is suitable for:
- Restaurants
- Hotel kitchens
- Bakeries
- Cafés and coffee shops
- Catering operations
- Fast food chains
- Commercial food preparation stations
- Central kitchens
- Supermarket back kitchens
- Frozen food storage
- Professional food service operations
FAQ
1. What temperature range does the freezer maintain?
The freezer maintains a stable temperature range between -22°C and -18°C, suitable for commercial frozen food storage.
2. What refrigerant does the unit use?
The YTA-120F FZ uses environmentally friendly R290 refrigerant, which provides excellent cooling efficiency with low environmental impact.
3. Is the freezer suitable for high-temperature commercial kitchens?
Yes. The unit is designed to operate in ambient temperatures ranging from 5°C to 43°C, making it suitable for demanding commercial kitchen environments.
4. Does the freezer require external drainage?
No. The electric defrost system includes condensate self-evaporation, eliminating the need for an external drain pipe in most installations.
5. What are the benefits of the forced-air cooling system?
The forced-air refrigeration system provides:
- Faster cooling recovery
- Even temperature distribution
- Stable internal temperature
- Reduced frost accumulation
- Improved frozen food preservation
6. Can the freezer be customized?
Yes. Optional configurations include:
- SUS304 stainless steel
- Adjustable casters
- LED lighting
- Door lock
- RS485 ModBus communication port
7. Is the stainless steel worktop suitable for food preparation?
Yes. The stainless steel worktop provides additional preparation space while improving workflow efficiency in commercial kitchens.
