Air-Cooled Vertical Two-Door Dual-Temperature Refrigerator/Freezer (470L)
Highlights
- Dual-temperature storage design: Freezer + Refrigerator in one cabinet
- Upper freezer zone: -22°C ~ -18°C
- Lower refrigerator zone: 0°C ~ +5°C
- Intelligent forced-air cooling system for even temperature distribution
- Eco-friendly R290 refrigerant (GWP=3)
- Automatic electric defrost with microprocessor control
- High-efficiency 60mm Cyclopentane insulation
- Food-grade SUS201 stainless steel liner
- Front-access removable filter for convenient maintenance
- Anti-corrosion evaporator coating for extended lifespan
- Optional AISI304 stainless steel upgrade
- Optional RS485 ModBus interface for smart monitoring integration
- Optional casters, adjustable feet, LED lighting, and door lock
Product Description
The Realmann YHA-2FR Air-Cooled Vertical Two-Door Dual-Temperature Refrigerator/Freezer is designed for commercial kitchens, hotels, restaurants, bakeries, supermarkets, and food service operations requiring simultaneous chilled and frozen storage in one unit. Featuring an intelligent dual-zone cooling system, the upper section maintains freezer temperatures of -22°C to -18°C, while the lower section provides refrigeration temperatures between 0°C and +5°C.
Powered by an energy-efficient R290 refrigeration system and advanced forced-air circulation technology, the YHA-2FR ensures accurate temperature control, balanced airflow, and reduced temperature fluctuations. Its durable stainless steel construction and automatic defrost technology provide reliable long-term performance while reducing maintenance workload.
Highlights
- Dual-temperature storage design: Freezer + Refrigerator in one cabinet
- Upper freezer zone: -22°C ~ -18°C
- Lower refrigerator zone: 0°C ~ +5°C
- Intelligent forced-air cooling system for even temperature distribution
- Eco-friendly R290 refrigerant (GWP=3)
- Automatic electric defrost with microprocessor control
- High-efficiency 60mm Cyclopentane insulation
- Food-grade SUS201 stainless steel liner
- Front-access removable filter for convenient maintenance
- Anti-corrosion evaporator coating for extended lifespan
- Optional AISI304 stainless steel upgrade
- Optional RS485 ModBus interface for smart monitoring integration
- Optional casters, adjustable feet, LED lighting, and door lock
Technical Specifications
| Item | Specification |
|---|---|
| Model | YHA-2FR |
| Product Type | Vertical Dual-Temperature Refrigerator/Freezer |
| Temperature Range | 0~+5°C / -22~-18°C |
| Refrigerator Capacity | 235L |
| Freezer Capacity | 235L |
| Total Net Capacity | 470L |
| Gross Capacity | 520L |
| Cooling System | Forced Air Circulation |
| Refrigeration Capacity | 500W |
| Refrigerant | R290 |
| Refrigerant Charge | 70g |
| Cooling Unit | Self-contained |
| Defrost System | Electric Defrost (Microprocessor Controlled) |
| Insulation Thickness | 60mm Cyclopentane |
| Exterior Material | SUS201 Stainless Steel + Galvanized Back & Bottom |
| Interior Material | SUS201 Stainless Steel |
| Shelves | 2 pcs Food-grade Plastic-coated Shelves |
| Shelf Size | 550 × 580 mm |
| Rated Power | 190W |
| Rated Current | 2A |
| Power Supply | 220–240V / 50–60Hz |
| Net Weight | 80kg |
| Gross Weight | 91kg |
| External Dimensions | 610 × 800 × 1980 mm |
| Internal Dimensions | 490 × 660 × 1420 mm |
| Package Dimensions | 640 × 830 × 2040 mm |
| Climate Class | 4 |
| Operating Temperature | Ambient 5°C~43°C |
| Test Standard | ISO 22041 |
Applications
Restaurants & Commercial Kitchens
Store frozen ingredients and fresh food simultaneously while reducing equipment footprint.
Hotels & Hospitality Projects
Ideal for hotel kitchens requiring separate storage for meats, vegetables, dairy products, and frozen items.
Bakeries & Dessert Shops
Store frozen raw materials while preserving fresh cream, cakes, and ingredients.
Supermarkets & Convenience Stores
Efficient backroom refrigeration and frozen food storage in one cabinet.
Catering & Food Processing Facilities
Supports organized ingredient management with independent temperature zones.
FAQ
Q1: What is the advantage of a dual-temperature refrigerator/freezer?
A dual-temperature design combines refrigeration and freezing functions in one cabinet, reducing floor space requirements and improving operational efficiency.
Q2: Can the freezer and refrigerator sections operate independently?
Yes. The intelligent airflow and temperature control system provides precise management for each temperature zone.
Q3: Does the unit require manual defrosting?
No. The YHA-2FR includes a microprocessor-controlled electric automatic defrost system.
Q4: Is R290 refrigerant environmentally friendly?
Yes. R290 has a Global Warming Potential (GWP) of only 3, making it an environmentally responsible refrigerant option.
Q5: Is the refrigerator suitable for high ambient temperature environments?
Yes. It supports operation under ambient temperatures from 5°C to 43°C and complies with Climate Class 4 requirements.
Q6: Does it support smart monitoring systems?
Yes. An optional RS485 communication port with ModBus protocol enables remote monitoring and system integration.
Realmann YHA-2FR Dual Temp Refrigerator Freezer 470L PDF
