SD/SC-BY Series 400L–1000L Commercial Curved Glass Display Freezer

The Realmann SD/SC-BY Commercial Curved Glass Display Freezer Series is designed for high-capacity frozen food merchandising in supermarkets, grocery stores, frozen food outlets, and commercial retail environments. Available in five cabinet sizes with usable capacities from 400L to 1000L, the series offers flexible horizontal product presentation for businesses requiring organized frozen storage.

A defining feature is the curved sliding glass lid design, which allows customers to view packaged frozen products from above and access merchandise through a sliding opening. Compared with upright display cabinets, the horizontal layout provides a different merchandising arrangement for supermarket freezer aisles and self-service retail sections.

The freezer incorporates 70mm thick cabinet insulation to help limit heat transfer and support low-temperature storage. A static refrigeration system uses a Cubigel compressor and R134a refrigerant, with the supplied technical specifications indicating a cabinet temperature of −18°C or below.

An electronic digital temperature controller provides a convenient interface for monitoring and adjusting refrigeration settings, replacing the traditional mechanical thermostat found in many basic chest freezer configurations.

Inside the cabinet, reinforced food baskets help organize packaged frozen merchandise. Depending on the selected model, four to eight baskets are included as standard. Built-in LED lighting improves visibility through the curved glass lids.

For everyday commercial use, the freezer features an aluminum alloy front rim, a protective front bumper, a bottom defrost drain, and four swivel casters. The bumper helps protect the cabinet from incidental contact with shopping carts or other retail equipment, while the casters simplify repositioning during store maintenance.

As a commercial refrigeration manufacturer, Realmann supports OEM/ODM and wholesale inquiries for supermarkets, frozen food distributors, and equipment importers seeking horizontal display freezer solutions.

Key Features & Benefits

1. High-Capacity Frozen Food Merchandising from 400L to 1000L

The BY Series offers five usable capacity configurations for different retail display requirements.

From the 400L model for smaller retail sections to the 1000L model for higher-volume frozen food merchandising, buyers can select a cabinet according to merchandise volume and installation space.

The largest model measures 2500 mm in width, providing an extended horizontal display format for large retail installations.

2. Curved Sliding Glass Lids for Customer-Friendly Access

The curved sliding glass lids provide a clear view of products stored inside the freezer.

Customers can slide the lids open to retrieve packaged frozen foods without lifting a hinged cover.

The curved glass profile also creates a distinctive presentation suitable for supermarket freezer aisles and branded frozen food merchandising areas.

3. 70mm Thick Cabinet Insulation

The cabinet incorporates a 70mm insulation layer designed to reduce heat transfer between the frozen compartment and the surrounding retail environment.

This insulation supports the refrigeration system in maintaining low cabinet temperatures.

Actual energy consumption depends on the full equipment configuration, ambient conditions, product loading, and lid-opening frequency.

4. Digital Temperature Display and Electronic Control

Unlike chest freezers equipped only with a mechanical adjustment dial, the BY Series includes an electronic digital temperature controller.

The digital interface allows operators to view temperature information and adjust control settings according to the configured functions.

This provides a practical monitoring interface for commercial frozen food storage.

5. Static Refrigeration with Cubigel Compressor

The BY Series uses a static cooling system with a Cubigel compressor.

Static refrigeration transfers heat through the cabinet’s cooling surfaces without relying on a fan to circulate air inside the storage compartment.

The supplied specifications indicate frozen storage at −18°C or below under rated conditions.

6. Reinforced Food Baskets for Organized Displays

Each model includes a standard set of reinforced storage baskets.

The basket quantity ranges from four to eight depending on model size, helping retailers organize frozen food products by type, package size, or brand.

The compartment layout also supports convenient stock replenishment and product separation.

7. Built-In LED Lighting

Integrated LED lighting is standard across the series.

It improves visibility of packaged frozen merchandise and helps staff identify products during stocking and daily operation.

8. Front Protective Bumper

A protective bumper is installed along the front of the cabinet to help reduce damage from incidental contact with shopping carts or other retail equipment.

This feature is particularly useful in busy supermarket aisles and commercial merchandising areas.

9. Aluminum Alloy Front Rim

The cabinet features an aluminum alloy rim along the front opening.

The metal trim provides a practical edge structure for the sliding glass lid assembly and supports a clean commercial appearance.

10. Bottom Defrost Drain and Four Swivel Casters

A bottom-mounted drain outlet facilitates water removal during manual defrosting and interior cleaning.

Four swivel casters allow the cabinet to be moved and repositioned more easily during installation, floor cleaning, or retail layout adjustments.

Technical Specifications

SD/SC-400BY to SD/SC-1000BY Model Comparison

Additional Product Specifications

All dimensions, capacities, basket quantities and refrigeration specifications are based on the supplied technical sheet. The model prefix SD/SC is reproduced as provided. Although both prefixes are shown, the table specifies frozen operation at ≤ −18°C for every model; any separate SC refrigeration configuration should be confirmed before publication.

Commercial Applications

1. Supermarket Frozen Food Aisles

The BY Series is suitable for frozen food merchandising in supermarkets requiring larger horizontal display capacity.

The 700L, 800L, and 1000L models provide extended display space for different packaged frozen product categories, while the front protective bumper helps protect the cabinet in shopping-cart traffic areas.

2. Ice Cream and Frozen Dessert Distribution

Frozen dessert distributors can use these freezers for packaged ice cream and related products when the cabinet temperature meets the product’s storage requirements.

The curved sliding lids allow customers to browse products, while the built-in LED lighting improves visibility.

3. Frozen Meat and Seafood Retail

The series can accommodate appropriately packaged frozen meat and seafood products requiring storage at or below −18°C.

Reinforced baskets help separate merchandise and support organized product placement.

All products must be stored according to applicable food safety regulations.

4. Grocery Chains and Neighborhood Markets

The 400L and 500L models provide compact options for smaller grocery stores or dedicated frozen food sections.

Their horizontal format allows refrigerated merchandise to be displayed beneath the glass lids, while the digital temperature controller supports routine operating checks.

5. High-Volume Frozen Food Merchandising

The 1000L BY model provides the largest usable capacity in the series.

With its 2500 mm wide cabinet and eight standard food baskets, it is suitable for commercial projects requiring substantial frozen product storage and organized merchandising.

OEM/ODM Customization and Wholesale Supply

Realmann provides manufacturing support for commercial refrigeration distributors, supermarkets, and frozen food brand projects.

Buyers can discuss product configurations, branding requirements, minimum order quantities, and shipping arrangements with Realmann.

Frequently Asked Questions (FAQ)

Q1: What is the Realmann BY Series curved glass display freezer?

The BY Series is a range of horizontal commercial display freezers with curved sliding glass lids.

It is designed for frozen food merchandising and is available in capacities from 400L to 1000L.

Q2: What makes the BY Series different from standard curved glass chest freezers?

The BY Series combines a digital temperature controller, front protective bumper, reinforced food baskets, and four swivel casters.

These features are intended to support routine operation in supermarkets and other commercial retail environments.

Q3: What is the operating temperature of the BY Series?

The supplied technical specifications indicate a cabinet temperature of −18°C or below.

Actual temperature performance depends on operating conditions, equipment settings, and product loading.

Q4: What is the benefit of the digital temperature controller?

A digital controller provides a convenient interface for temperature monitoring and adjustment.

The exact available functions depend on the controller model and system configuration.

Q5: What capacity options are available?

The series includes five usable capacities: 400L, 500L, 700L, 800L, and 1000L.

These sizes allow buyers to select the cabinet according to floor space and frozen merchandising requirements.

Q6: How many storage baskets are included?

The standard basket quantities are four for the 400BY, five for the 500BY, six for the 700BY and 800BY, and eight for the 1000BY.

Q7: Does the freezer use fan cooling?

No. The technical specifications identify the refrigeration method as static cooling.

Static systems do not rely on an internal circulation fan and may require periodic manual defrosting.

Q8: How thick is the insulation?

The freezer incorporates a 70mm cabinet insulation layer.

This helps reduce heat transfer through the cabinet body during frozen storage.

Q9: What refrigerant and compressor are used?

The supplied technical sheet lists R134a refrigerant and a Cubigel compressor for all five models.

Buyers should confirm refrigerant compliance with the destination market before ordering.

Q10: Is the freezer easy to move?

The cabinet uses four swivel casters, allowing it to be repositioned during installation or cleaning.

The equipment should be moved according to appropriate handling procedures, particularly when loaded.

Q11: What is the purpose of the front protective bumper?

The bumper helps protect the front cabinet surface from incidental impacts in commercial retail environments, including contact with shopping carts.

Q12: Does the freezer have a defrost drain?

Yes. A bottom-mounted drain outlet facilitates water removal during manual defrosting and cleaning.

Q13: Can Realmann supply these freezers for wholesale projects?

Yes. Realmann supports commercial refrigeration wholesale and OEM/ODM inquiries.

Buyers can discuss model selection, order quantities, project requirements, and shipment arrangements.
