2000 Three-Layer Right-Angle Cake Display Case (Air-Cooled)
Features
- Precise Temperature Control (-2°C to +5°C)
Maintains stable conditions for cakes and delicate desserts - Uniform Airflow Cooling System
Rear-outlet & front-inlet design ensures even temperature distribution - Energy-Efficient Operation
Inverter compressor + EC fans, 13.5 kWh/24h consumption - Large-Capacity Premium Display
2000 mm wide, 3-layer structure with Low-E anti-fog glass - Smart & Easy Maintenance Design
Natural defrost, removable filter, RS485 remote monitoring support
The 2000 Three-Layer Right-Angle Cake Display Case (Air-Cooled) is a high-capacity refrigeration solution designed for large-scale bakeries, cafés, and retail environments that demand maximum display space, consistent cooling, and premium presentation. With an extended 2000 mm width, 841L net volume, and 2.0 m² display area, it offers exceptional merchandising capability for cakes, pastries, and chilled desserts.
Built with an inverter compressor and eco-friendly R290 refrigerant, the system delivers reliable and energy-efficient cooling. The advanced forced air circulation system, featuring a rear air outlet and front air inlet, ensures uniform cold air distribution across all three display levels, minimizing temperature fluctuations and preserving product quality.
The cabinet combines AISI 304 stainless steel construction, Low-E anti-fog double-glazed glass, and intelligent control systems, ensuring durability, hygiene, and superior product visibility. Designed for continuous commercial operation, it also integrates easy maintenance access and smart monitoring capabilities.
Features
- Precise Temperature Control (-2°C to +5°C)
Maintains stable conditions for cakes and delicate desserts - Uniform Airflow Cooling System
Rear-outlet & front-inlet design ensures even temperature distribution - Energy-Efficient Operation
Inverter compressor + EC fans, 13.5 kWh/24h consumption - Large-Capacity Premium Display
2000 mm wide, 3-layer structure with Low-E anti-fog glass - Smart & Easy Maintenance Design
Natural defrost, removable filter, RS485 remote monitoring support
Technical Specifications
| Category | Specification |
|---|---|
| Model | YCA-RA200R3-E |
| Temperature Range | -2°C to +5°C |
| Cooling Type | Air-cooled (forced air circulation) |
| Refrigerant | R290 |
| Compressor | Inverter compressor |
| Fan System | EC evaporator fan + EC condenser fan |
| Defrost System | Natural defrost (no drain required) |
| External Material | SUS304 stainless steel |
| Internal Material | AISI 304 stainless steel |
| Glass Type | Double-layer Low-E anti-fog glass |
| Door Type | Sliding glass door with self-closing |
| Lighting | 6× LED lights (4000K / 5000K, replaceable) |
| Lighting Control | Independent switch |
| Effective Volume | 841L |
| Display Area | 2.0 m² |
| External Dimensions (W×D×H) | 2000 × 754 × 1473 mm |
| Internal Dimensions (W×D×H) | 1850 × 610 × 745 mm |
| Top Shelf Size | 1850 × 293 mm |
| Middle Shelf Size | 1850 × 393 mm |
| Bottom Shelf Size | 1850 × 428 mm |
| Power Supply | 220–240V AC / 50–60 Hz |
| Rated Power | 650W |
| Rated Current | 4.4A |
| Energy Consumption (24h) | 13.5 kWh |
| Annual Energy Consumption | 4927 kWh |
| Net Weight / Gross Weight | 300 kg / 330 kg |
| Climate Class | 3 |
| Test Standard | ISO 23953-2 |
Applications
- Large Bakery Chains – High-capacity display for multiple product categories
- Cafés & Dessert Shops – Enhances visual merchandising and customer engagement
- Hotels & Buffet Restaurants – Professional dessert presentation with stable cooling
- Supermarkets & Hypermarkets – Ideal for packaged desserts and chilled bakery items
- Premium Patisseries – High-end display with excellent lighting and transparency
FAQ
Q1: What makes this model suitable for large-scale operations?
Its 2000 mm width, 841L capacity, and 3-layer display design provide ample space for high-volume product display.
Q2: How does the airflow system maintain consistent temperature?
The rear-outlet/front-inlet forced air system distributes cold air evenly, reducing temperature variation across shelves.
Q3: Is the unit energy efficient for its size?
Yes. Despite its large capacity, it operates at 13.5 kWh per 24 hours, thanks to inverter and EC fan technology.
Q4: Will the glass remain clear in humid environments?
Yes. The Low-E double-glazed anti-fog glass ensures high visibility at all times.
Q5: Does it require a drainage system?
No. The natural defrost system includes an evaporating tray, eliminating external drainage requirements.
Q6: Can it support smart monitoring?
Yes. It features RS485 communication with ModBus protocol for remote monitoring and system integration.
